HT1006 / HTV1006 Hyper Tough Indoor Analog Mini Timer

 Features

• 1 polarized outlet
• Programmable in 30-minute intervals (up to 24 ON/OFF cycles per day)
• CFL & LED compatible
• Indoor use only
• Manual override switch

Setup Instructions

1. Setting the Time:

   • Turn the dial clockwise until the current time aligns with the “Time Now” arrow.
   • The dial has a dark section for nighttime hours and a white section for daytime.

2. Programming ON/OFF Periods:

   • Pull up all tabs (pins) initially.
   • Push down tabs corresponding to the desired ON period (e.g., 6:00 PM to 10:00 PM).

3. Connecting the Appliance:

   • Plug the appliance into the timer and the timer into the power source.
   • Ensure the appliance is turned on.

4. Manual Override:

   • Use the switch on top to override the timer.
   • “OUTLET ON” keeps the appliance on permanently.
   • “TIMER ON” resumes scheduled control.

Safety Warnings

• Only connect to a 125V, 60Hz power source.
• Do not exceed 15A/1875W resistive or 1250W tungsten load.
• Not for use with heating appliances.
• Indoor use only.
• Do not immerse in water or disassemble.
